Working principle and purpose of the product:

  & nbsp; & nbsp; & nbsp; When water is supplied from the inlet end of the pipeline, due to the normally open needle valve, ball valve, and float valve, water enters the water tank through the micro filter, needle valve, control room, ball valve, and float valve. At this time, no pressure is formed in the control room, and the main valve opens, allowing the water tower (pool) to supply water. When the water level of the water tower (pool) rises to the set height, the floating ball rises and closes the floating ball valve, controlling the indoor water pressure to increase, pushing the main valve to close, and stopping the water supply. When the water level drops, the floating ball valve opens again, the water pressure in the control room decreases, and the main valve opens again to continue supplying water, maintaining the set height of the liquid level. This series of remote control float ball valves is used for liquid level control of water towers, pools, and other facilities in water supply network systems such as high-rise buildings and living areas.

Product Structure Features:

  The remote-controlled floating ball valve can be installed at any position according to the height and usage space of the pool, with convenient maintenance, debugging, and inspection, reliable sealing, and long service life. The diaphragm remote control floating ball valve has reliable performance, high strength, and flexible action, and is suitable for pipelines with diameters below DN450mm.
