Working principle and purpose of the product:

The bimetallic strip drain valve is driven by a bimetallic strip temperature sensing element to open and close the valve core. When the drain valve is just started, low-temperature condensed water appears in the pipeline, and the valve core of the bimetallic flat drain valve is in the open position under the elastic force of the spring. As the temperature of the condensed water gradually increases, the bimetallic sensing element begins to bend and deform, and the valve core of the drain valve is pushed towards the closed position. Before the condensate reaches saturation temperature, the bimetallic strip drain valve is completely closed. There is always high-temperature condensed water in front of the valve, with no steam leakage and good energy-saving effect.

Product Structure Features:

① CS17H type drain valve can be installed at any angle and the drainage temperature can be adjusted at any time.

② Anti water impact, excellent exhaust performance.

 ③ The discharge temperature of condensate can be adjusted to effectively utilize the sensible heat of condensate.

④ CS17H type drain valve with spherical closing method has a long service life.

⑤ There is always condensed water in front of the CS17H drain valve, forming a water seal and no steam leakage.
